Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 119 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 C06Eh PORTE Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C072h PORTJ Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C083h PORT1 Open Drain Control Register 1 ODR1 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C084h PORT2 Open Drain Control Register 0 ODR0 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C085h PORT2 Open Drain Control Register 1 ODR1 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C086h PORT3 Open Drain Control Register 0 ODR0 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C087h PORT3 Open Drain Control Register 1 ODR1 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C096h PORTB Open Drain Control Register 0 ODR0 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C097h PORTB Open Drain Control Register 1 ODR1 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C098h PORTC Open Drain Control Register 0 ODR0 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C099h PORTC Open Drain Control Register 1 ODR1 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C09Ch PORTE Open Drain Control Register 0 ODR0 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C09Dh PORTE Open Drain Control Register 1 ODR1 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C0A4h PORTJ Open Drain Control Register 0 ODR0 8 8, 16 2 or 3 PCLKB 2 ICLK section 21.
0008 C0C0h PORT0 Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0C1h PORT1 Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0C2h PORT2 Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0C3h PORT3 Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0C4h PORT4 Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0CBh PORTB Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0CCh PORTC Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0CDh PORTD Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0CEh PORTE Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0D2h PORTJ Pull-Up Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0E1h PORT1 Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0E2h PORT2 Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0E3h PORT3 Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0EBh PORTB Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0ECh PORTC Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0EDh PORTD Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0EEh PORTE Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C0F2h PORTJ Drive Capacity Control Register DSCR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C11Fh MPC Write-Protect Register PWPR 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C120h PORT Port Switching Register B PSRB 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C143h MPC P03 Pin Function Control Register P03PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C145h MPC P05 Pin Function Control Register P05PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C147h MPC P07 Pin Function Control Register P07PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C14Ch MPC P14 Pin Function Control Register P14PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C14Dh MPC P15 Pin Function Control Register P15PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C14Eh MPC P16 Pin Function Control Register P16PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C14Fh MPC P17 Pin Function Control Register P17PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C151h MPC P21 Pin Function Control Register P21PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C152h MPC P22 Pin Function Control Register P22PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C155h MPC P25 Pin Function Control Register P25PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C156h MPC P26 Pin Function Control Register P26PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C157h MPC P27 Pin Function Control Register P27PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C158h MPC P30 Pin Function Control Register P30PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C159h MPC P31 Pin Function Control Register P31PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C160h MPC P40 Pin Function Control Register P40PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C161h MPC P41 Pin Function Control Register P41PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
0008 C162h MPC P42 Pin Function Control Register P42PFS 8 8 2 or 3 PC
LKB 2 ICLK section 22.
000
8 C163h MPC P43 Pin Function Control Register P43PFS 8 8 2 or 3 PCLKB 2 ICLK section 22.
Table 5.1 List of I/O Registers (Address Order) (15/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
