RX23W Group 36. CAN Module (RSCAN)
Table 36.8 Registers Initialized in Global Reset Mode or Channel Reset Mode
Register Bit/Flag
CTRL CHMDC[1:0]
CTRH CTMS[1:0], CTME
STSL CHLTSTS, EPSTS, BOSTS, TRMSTS, RECSTS, COMSTS
STSH REC[7:0], TEC[7:0]
ERFLL ADERR, B0ERR, B1ERR, CERR, AERR, FERR, SERR, ALF, BLF, OVLF, BORF, BOEF, EPF, EWF, BEF
ERFLH CRCREG[14:0]
CFCCL0 When transmit/receive FIFO buffer is in transmit mode: CFE
CFSTS0 When transmit/receive FIFO buffer is in transmit mode: CFMC[5:0], CFTXIF, CFRXIF, CFMLT, CFFLL,
CFEMP
TMCp TMOM, TMTAR, TMTR
TMSTSp TMTARM, TMTRM, TMTRF[1:0], TMTSTS
TMTRSTS TMTRSTSp
TMTCSTS TMTCSTSp
TMTASTS TMTASTSp
THLCC0 THLE
THLSTS0 THLMC[3:0], THLIF, THLELT, THLFLL, THLEMP
GTINTSTS THIF0, CFTIF0, TAIF0, TSIF0
Table 36.9 Registers Initialized Only in Global Reset Mode
Register Bit/Flag
GSTS GHLTSTS
GERFLL THLES, MES, DEF
GTSC TS[15:0]
RMND0 RMNSn
RFCCm RFE
RFSTSm RFMC[5:0], RFIF, RFMLT, RFFLL, RFEMP
CFCCL0 When transmit/receive FIFO buffer is in receive mode: CFE
CFSTS0 When transmit/receive FIFO buffer is in receive mode: CFMC[5:0], CFTXIF, CFRXIF, CFMLT, CFFLL,
CFEMP
RFMSTS RFmMLT
CFMSTS CF0MLT
RFISTS RFmIF
CFISTS CF0IF
GTSTCFG RTMPS[2:0]
GTSTCTRL RTME
