RX23W Group 5. I/O Registers
000A 83AAh RSCAN Receive Buffer Register 0CH RMDF10 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83ACh RSCAN Receive Rule Entry Register 1AL GAFLIDL1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83ACh RSCAN Receive Buffer Register 0DL RMDF20 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83AEh RSCAN Receive Rule Entry Register 1AH GAFLIDH1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83AEh RSCAN Receive Buffer Register 0DH RMDF30 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B0h RSCAN Receive Rule Entry Register 1BL GAFLML1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B0h RSCAN Receive Buffer Register 1AL RMIDL1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B2h RSCAN Receive Rule Entry Register 1BH GAFLMH1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B2h RSCAN Receive Buffer Register 1AH RMIDH1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B4h RSCAN Receive Rule Entry Register 1CL GAFLPL1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B4h RSCAN Receive Buffer Register 1BL RMTS1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B6h RSCAN Receive Rule Entry Register 1CH GAFLPH1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B6h RSCAN Receive Buffer Register 1BH RMPTR1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B8h RSCAN Receive Rule Entry Register 2AL GAFLIDL2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83B8h RSCAN Receive Buffer Register 1CL RMDF01 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83BAh RSCAN Receive Rule Entry Register 2AH GAFLIDH2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83BAh RSCAN Receive Buffer Register 1CH RMDF11 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83BCh RSCAN Receive Rule Entry Register 2BL GAFLML2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83BCh RSCAN Receive Buffer Register 1DL RMDF21 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83BEh RSCAN Receive Rule Entry Register 2BH GAFLMH2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83BEh RSCAN Receive Buffer Register 1DH RMDF31 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C0h RSCAN Receive Rule Entry Register 2CL GAFLPL2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C0h RSCAN Receive Buffer Register 2AL RMIDL2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C2h RSCAN Receive Rule Entry Register 2CH GAFLPH2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C2h RSCAN Receive Buffer Register 2AH RMIDH2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C4h RSCAN Receive Rule Entry Register 3AL GAFLIDL3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C4h RSCAN Receive Buffer Register 2BL RMTS2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C6h RSCAN Receive Rule Entry Register 3AH GAFLIDH3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C6h RSCAN Receive Buffer Register 2BH RMPTR2 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C8h RSCAN Receive Rule Entry Register 3BL GAFLML3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83C8h RSCAN Receive Buffer Register 2CL RMDF02 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83CAh RSCAN Receive Rule Entry Register 3BH GAFLMH3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83CAh RSCAN Receive Buffer Register 2CH RMDF12 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83CCh RSCAN Receive Rule Entry Register 3CL GAFLPL3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83CCh RSCAN Receive Buffer Register 2DL RMDF22 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83CEh RSCAN Receive Rule Entry Register 3CH GAFLPH3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83CEh RSCAN Receive Buffer Register 2DH RMDF32 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D0h RSCAN Receive Rule Entry Register 4AL GAFLIDL4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D0h RSCAN Receive Buffer Register 3AL RMIDL3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D2h RSCAN Receive Rule Entry Register 4AH GAFLIDH4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D2h RSCAN Receive Buffer Register 3AH RMIDH3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D4h RSCAN Receive Rule Entry Register 4BL GAFLML4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D4h RSCAN Receive Buffer Register 3BL RMTS3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D6h RSCAN Receive Rule Entry Register 4BH GAFLMH4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D6h RSCAN Receive Buffer Register 3BH RMPTR3 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D8h RSCAN Receive Rule Entry Register 4CL GAFLPL4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83D8h RSCAN Receive Buffer Register 3CL RMDF03 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83DAh RSCAN Receive Rule Entry Register 4CH GAFLPH4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83DAh RSCAN Receive Buffer Register 3CH RMDF13 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83DCh RSCAN Receive Rule Entry Register 5AL GAFLIDL5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83DCh RSCAN Receive Buffer Register 3DL RMDF23 16 16 2 or 3 PCLK
B 2 ICLK section 36.
000
A 83DEh RSCAN Receive Rule Entry Register 5AH GAFLIDH5 16 16 2 or 3 PCLKB 2 ICLK section 36.
Table 5.1 List of I/O Registers (Address Order) (23/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
