Renesas RX Series

R01UH0823EJ0100 Rev.1.00 Page 128 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
000A 83DEh RSCAN Receive Buffer Register 3DH RMDF33 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E0h RSCAN Receive Rule Entry Register 5BL GAFLML5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E0h RSCAN Receive Buffer Register 4AL RMIDL4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E2h RSCAN Receive Rule Entry Register 5BH GAFLMH5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E2h RSCAN Receive Buffer Register 4AH RMIDH4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E4h RSCAN Receive Rule Entry Register 5CL GAFLPL5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E4h RSCAN Receive Buffer Register 4BL RMTS4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E6h RSCAN Receive Rule Entry Register 5CH GAFLPH5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E6h RSCAN Receive Buffer Register 4BH RMPTR4 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E8h RSCAN Receive Rule Entry Register 6AL GAFLIDL6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83E8h RSCAN Receive Buffer Register 4CL RMDF04 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83EAh RSCAN Receive Rule Entry Register 6AH GAFLIDH6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83EAh RSCAN Receive Buffer Register 4CH RMDF14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83ECh RSCAN Receive Rule Entry Register 6BL GAFLML6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83ECh RSCAN Receive Buffer Register 4DL RMDF24 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83EEh RSCAN Receive Rule Entry Register 6BH GAFLMH6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83EEh RSCAN Receive Buffer Register 4DH RMDF34 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F0h RSCAN Receive Rule Entry Register 6CL GAFLPL6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F0h RSCAN Receive Buffer Register 5AL RMIDL5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F2h RSCAN Receive Rule Entry Register 6CH GAFLPH6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F2h RSCAN Receive Buffer Register 5AH RMIDH5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F4h RSCAN Receive Rule Entry Register 7AL GAFLIDL7 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F4h RSCAN Receive Buffer Register 5BL RMTS5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F6h RSCAN Receive Rule Entry Register 7AH GAFLIDH7 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F6h RSCAN Receive Buffer Register 5BH RMPTR5 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F8h RSCAN Receive Rule Entry Register 7BL GAFLML7 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83F8h RSCAN Receive Buffer Register 5CL RMDF05 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83FAh RSCAN Receive Rule Entry Register 7BH GAFLMH7 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83FAh RSCAN Receive Buffer Register 5CH RMDF15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83FCh RSCAN Receive Rule Entry Register 7CL GAFLPL7 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83FCh RSCAN Receive Buffer Register 5DL RMDF25 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83FEh RSCAN Receive Rule Entry Register 7CH GAFLPH7 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 83FEh RSCAN Receive Buffer Register 5DH RMDF35 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8400h RSCAN Receive Rule Entry Register 8AL GAFLIDL8 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8400h RSCAN Receive Buffer Register 6AL RMIDL6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8402h RSCAN Receive Rule Entry Register 8AH GAFLIDH8 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8402h RSCAN Receive Buffer Register 6AH RMIDH6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8404h RSCAN Receive Rule Entry Register 8BL GAFLML8 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8404h RSCAN Receive Buffer Register 6BL RMTS6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8406h RSCAN Receive Rule Entry Register 8BH GAFLMH8 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8406h RSCAN Receive Buffer Register 6BH RMPTR6 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8408h RSCAN Receive Rule Entry Register 8CL GAFLPL8 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8408h RSCAN Receive Buffer Register 6CL RMDF06 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 840Ah RSCAN Receive Rule Entry Register 8CH GAFLPH8 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 840Ah RSCAN Receive Buffer Register 6CH RMDF16 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 840Ch RSCAN Receive Rule Entry Register 9AL GAFLIDL9 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 840Ch RSCAN Receive Buffer Register 6DL RMDF26 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 840Eh RSCAN Receive Rule Entry Register 9AH GAFLIDH9 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 840Eh RSCAN Receive Buffer Register 6DH RMDF36 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8410h RSCAN Receive Rule Entry Register 9BL GAFLML9 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8410h RSCAN Receive Buffer Register 7AL RMIDL7 16 16 2 or 3 PCLK
B 2 ICLK section 36.
000
A 8412h RSCAN Receive Rule Entry Register 9BH GAFLMH9 16 16 2 or 3 PCLKB 2 ICLK section 36.
Table 5.1 List of I/O Registers (Address Order) (24/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
