R01UH0823EJ0100 Rev.1.00 Page 1280 of 1823

Jul 31, 2019

RX23W Group 36. CAN Module (RSCAN)

Figure 36.14 CAN Channel Interrupt Block Diagram

Transmit/receive FIFO receive interrupt

CFSTS0.CFRXIF

CFCCL0.CFRXIE

TMIEC.TMIEp

TMSTSp.TMTRF0

TMSTSp.TMTRF1

CTRH.TAIE

CFSTS0.CFTXIF

CFCCL0.CFTXIE

THLSTS0.THLIF

THLCC0.THLIE

ERFLL.BEF

CTRL.BEIE

ERFLL.EWF

CTRL.EWIE

ERFLL.EPF

CTRL.EPIE

ERFLL.BOEF

CTRL.BOEIE

ERFLL.BORF

CTRL.BORIE

ERFLL.OVLF

CTRL.OLIE

ERFLL.BLF

CTRL.BLIE

ERFLL.ALF

CTRL.ALIE

Channel transmit interrupt

Channel error interrupt
