RX23W Group 40. SD Host Interface (SDHIa)

Figure 40.10 Issuing the Single Block Read Command

Clear the flag register

Set the SDCLKCR register.

SDSIZE = Transfer data size

SDIMSK1 = 0000 FFFEh

SDIMSK2 = 0000 7F80h

Response end or

error occurred?

SDSTS1 = 0000 FFFEh Clear the flags.

SDARG = Argument field value

SDCMD = 0000 0011h

CMD17 (single block read)

issued

Error (communication error or timeout)

Read the SDRSP10 register Check the response.

SDIMSK1 = 0000 FFFBh

SDIMSK2 = 0000 7E80h

Enable the access end interrupt

Enable the BRE interrupt

Is the BRE flag 1 or

did an error occur?

SDSTS2 = 0000 FEFFh Clear the flags.

Read the amount of data set in the

SDSIZE.LEN[9:0] bits from the SDBUFR

Read data.

Access end?

SDSTS1 = 0000 FFFBh Clear the flags.

Error processing

(clear the interrupt flags)

Yes

Start

End

Error (communication error or timeout)
