Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 1576 of 1823
Jul 31, 2019
RX23W Group 44. 12-Bit A/D Converter (S12ADE)
Figure 44.4 Explanation of Compare Function Window B Compare Conditions
(1) Compare conditions when the window function is disabled
CMPLB = 0 CMPLB = 1
ADWINLLB value ≤ A/D-converted value Not met ADWINLLB value < A/D-converted value Met
ADWINLLB value > A/D-converted value Met ADWINLLB value ≥ A/D-converted value Not met
(2) Comparison conditions when the window function is enabled
CMPLB = 0
A/D-converted value < ADWINULB value Met
ADWINLLB value ≤ A/D-converted value ≤ ADWINULB value Not met
A/D-converted value < ADWINLLB value Met
CMPLB = 1
A/D-converted value ≤ ADWINULB value Not met
ADWINLLB value < A/D-converted value < ADWINULB value Met
A/D-converted value ≤ ADWINLLB value Not met
