R01UH0823EJ0100 Rev.1.00 Page 1611 of 1823

Jul 31, 2019

RX23W Group 44. 12-Bit A/D Converter (S12ADE)

Figure 44.26 Example of Disconnection Detection When Discharge is Selected

Precharge

control signal

Discharge

control signal

Analog input

ANn

OFF

R = 1 M

Disconnection

Sampling capacitance

Example of the

external circuit

Discharge

VREFL0

or AVSS0

Note 1. The converted result should be used after fully evaluated because the result data when disconnection

occurs varies depending on the external circuit.
