R01UH0823EJ0100 Rev.1.00 Page 1645 of 1823
Jul 31, 2019
RX23W Group 47. Comparator B (CMPBa)
Table 47.4 Procedure for Setting Registers Associated with Comparator B When Window Function is Enabled
(n = 2, 3)
Step
No. Register Bit Setting
1 PijPFS of the port to which
the CMPBn pin is assigned
ASEL 1
2 CPB1MD CPBSPDMD 0 (always specify high-speed mode)
3 CPB1CNT1 CPBnINI Powered on: 1
4 CPB1F Select whether to enable or disable the filter and select the sampling clock.
5 CPB1CNT2 CPBnWCP 1 (operation enabled)
6 Waiting for the comparator stabilization time (min. 100 μs)
7 CPB1OCR CPBnOP, CPBnOE Set the CMPOBn output (select the polarity and set output enabled or
disabled).
8 CPB1INT CPBnINTEN When using an interrupt: 1 (interrupt enabled)
CPBnINTEG When using an interrupt or the ELC: Select the input edge (1 = both
edges or 0 = single edge).
CPBnINTPL When using an interrupt or the ELC: For CPBnINTEG = 0 (single edge
selected), select the input polarity (1 = rising edge or 0 = falling edge).
9 IPR104 (comparator B2),
IPR105 (comparator B3)
IPR[3:0] When using an interrupt: Select the interrupt priority level.
IR104 (comparator B2),
IR105 (comparator B3)
IR When using an interrupt: 0 (no interrupt requested: initialization)
IER07 IEN0 (comparator B2),
IEN1 (comparator B3)
When using an interrupt: 1 (interrupt enabled)
To Next Page
