RX23W Group 50. Flash Memory (FLASH)
STOP Bit (Forced Processing Stop)
This bit is used to forcibly stop the processing (blank check, block erase, or all-block erase) being executed.
After setting this bit to 1, wait until the FSTATR1.FRDY flag is 1 (processing completed) before setting the OPST bit to
0.
OPST Bit (Processing Start)
This bit is used to execute the command set in the CMD[2:0] bits.
This bit is not set to 0 again even when the processing is completed. Confirm that the FSTATR1.FRDY flag is 1
(processing completed) before setting the OPST bit to 0 again. After that, confirm that the FRDY flag is 0 before
executing the next processing.
Table 50.4 Setting Address for All-Block Erase
Target Memory Size FSARH/FSARL FEARH/FEARL
ROM 512 Kbytes FC18 0000h FC1F FFF8h
384 Kbytes FC1A 0000h FC1F FFF8h
E2 DataFlash 8 Kbytes FE00 0000h FE00 1FFFh

Renesas RX Series Specifications

General

Core	RXv1, RXv2, RXv3
Flash Memory	Up to 8 MB
RAM	Up to 1 MB
Operating Voltage	1.62V to 5.5V
Operating Temperature	-40°C to +85°C or +105°C
Package	BGA, LQFP
ADC Resolution	12-bit
DAC Resolution	12-bit
Communication Interfaces	SCI, SPI, I2C, USB, Ethernet, CAN
Architecture	32-bit
Security Features	Memory Protection Unit (MPU)
