RX23W Group 51. Electrical Characteristics
Table 51.4 DC Characteristics (2)
Conditions: 1.8 V ≤ VCC = VCC_USB = VCC_RF = AVCC_RF ≤ 2.7 V, 1.8 V ≤ AVCC0 < 2.7 V,
VSS = AVSS0 = VSS_USB = VSS_RF = 0 V, T
a
= –40 to +85°C
Item Symbol Min. Typ. Max. Unit
Test
Conditions
Schmitt trigger
input voltage
Ports 16, 17, port B5
(5 V tolerant)
V
IH
VCC × 0.8 — 5.8 V
Ports 14, 15, ports 21, 22, 25 to 27,
ports 30, 31, 35 to 37,
ports B0, B1, B3, B5, B7,
ports C0, C2 to C7,
ports D3,
ports E0 to E4,
port J3, RES#
VCC × 0.8 — VCC + 0.3
Ports 03, 05, 07, ports 40 to 47 AVCC0 × 0.8 — AVCC0 + 0.3
Ports 03, 05, 07, ports 40 to 47 V
IL
–0.3 — AVCC0 × 0.2
Ports other than above –0.3 — VCC × 0.2
Ports 03, 05, 07, ports 40 to 47 ΔV
T
AVCC0 × 0.01 — —
Ports other than above VCC × 0.01 — —
Input level
voltage (except
for Schmitt
trigger input
pins)
MD V
IH
VCC × 0.9 — VCC + 0.3 V
EXTAL (external clock input) VCC × 0.8 — VCC + 0.3
MD V
IL
–0.3 — VCC × 0.1
EXTAL (external clock input) –0.3 — VCC × 0.2
Table 51.5 DC Characteristics (3)
Conditions: 1.8 V ≤ VCC = VCC_USB = AVCC0 = VCC_RF = AVCC_RF ≤ 3.6 V, VSS = AVSS0 = VSS_USB = VSS_RF = 0 V,
T
a
= –40 to +85°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Input leakage current RES#, MD, port 35
I
in
 ——1.0μAV
in
= 0 V, VCC
Three-state leakage
current (off-state)
Ports for 5 V tolerant
I
TSI
 ——1.0μAV
in
= 0 V, 5.8 V
Ports except for 5 V tolerant — — 0.2 μA V
in
= 0 V, VCC
Input capacitance All input pins
(except for port 35, USB0_DM,
USB0_DP)
C
in
— — 15 pF V
in
= 0 mV,
f = 1 MHz,
T
a
= 25°C
Port 35, USB0_DM, USB0_DP — — 30
Table 51.6 DC Characteristics (4)
Conditions: 1.8 V ≤ VCC = VCC_USB = AVCC0 = VCC_RF = AVCC_RF ≤ 3.6 V, VSS = AVSS0 = VSS_USB = VSS_RF = 0 V,
T
a
= –40 to +85°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Input pull-up resistor All ports
(except for port 35)
R
U
10 20 50 kΩ V
in
= 0 V
