R01UH0823EJ0100 Rev.1.00 Page 283 of 1823

Jul 31, 2019

RX23W Group 15. Interrupt Controller (ICUb)

VBATEN Bit (VBATT Voltage Monitoring Interrupt Enable)

This bit enables the VBATT voltage monitoring interrupt.

A 1 can be written to this bit only once, and subsequent write accesses are no longer enabled.

Writing 0 to this bit is disabled.
