Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 288 of 1823
Jul 31, 2019
RX23W Group 15. Interrupt Controller (ICUb)
Table 15.3 Interrupt Vector Table (1/6)
Source of
Interrupt
Request
Generation Name
Vector
No.*
1
Vector
Address
Offset
Form of
Interrupt
Detection
CPU DTC DMAC sstb Return
IER IPR DTCER
— For an unconditional trap 0 0000h — N/A N/A N/A N/A — — —
— For an unconditional trap 1 0004h — N/A N/A N/A N/A — — —
— For an unconditional trap 2 0008h — N/A N/A N/A N/A — — —
— For an unconditional trap 3 000Ch — N/A N/A N/A N/A — — —
— For an unconditional trap 4 0010h — N/A N/A N/A N/A — — —
— For an unconditional trap 5 0014h — N/A N/A N/A N/A — — —
— For an unconditional trap 6 0018h — N/A N/A N/A N/A — — —
— For an unconditional trap 7 001Ch — N/A N/A N/A N/A — — —
— For an unconditional trap 8 0020h — N/A N/A N/A N/A — — —
— For an unconditional trap 9 0024h — N/A N/A N/A N/A — — —
— For an unconditional trap 10 0028h — N/A N/A N/A N/A — — —
— For an unconditional trap 11 002Ch — N/A N/A N/A N/A — — —
— For an unconditional trap 12 0030h — N/A N/A N/A N/A — — —
— For an unconditional trap 13 0034h — N/A N/A N/A N/A — — —
— For an unconditional trap 14 0038h — N/A N/A N/A N/A — — —
— For an unconditional trap 15 003Ch — N/A N/A N/A N/A — — —
BSC BUSERR 16 0040h Level
 N/A N/A N/A IER02.IEN0 IPR000 —
— Reserved 17 0044h — N/A N/A N/A N/A — — —
— Reserved 18 0048h — N/A N/A N/A N/A — — —
— Reserved 19 004Ch — N/A N/A N/A N/A — — —
— Reserved 20 0050h — N/A N/A N/A N/A — — —
— Reserved 21 0054h — N/A N/A N/A N/A — — —
— Reserved 22 0058h — N/A N/A N/A N/A — — —
FCU FRDYI 23 005Ch Edge
 N/A N/A N/A IER02.IEN7 IPR002 —
— Reserved 24 0060h — N/A N/A N/A N/A — — —
— Reserved 25 0064h — N/A N/A N/A N/A — — —
— Reserved 26 0068h — N/A N/A N/A N/A — — —
ICU SWINT 27 006Ch Edge
N/A N/A IER03.IEN3 IPR003 DTCER027
CMT0 CMI0 28 0070h Edge
N/A IER03.IEN4 IPR004 DTCER028
CMT1 CMI1 29 0074h Edge
N/A IER03.IEN5 IPR005 DTCER029
CMT2 CMI2 30 0078h Edge
N/A IER03.IEN6 IPR006 DTCER030
CMT3 CMI3 31 007Ch Edge
N/A IER03.IEN7 IPR007 DTCER031
CAC FERRF 32 0080h Level
 N/A N/A N/A IER04.IEN0 IPR032 —
MENDF 33 0084h Level
 N/A N/A N/A IER04.IEN1 IPR033 —
OVFF 34 0088h Level
 N/A N/A N/A IER04.IEN2 IPR034 —
— Reserved 35 008Ch — N/A N/A N/A N/A — — —
USB0 D0FIFO0 36 0090h Edge
N/A IER04.IEN4 IPR036 DTCER036
D1FIFO0 37 0094h Edge
N/A IER04.IEN5 IPR037 DTCER037
USBI0 38 0098h Edge
 N/A N/A N/A IER04.IEN6 IPR038 —
— Reserved 39 009Ch — N/A N/A N/A N/A — — —
SDHI SBFAI 40 00A0h Edge
N/A IER05.IEN0 IPR040 DTCER040
CDETI 41 00A4h Level
 N/A N/A N/A IER05.IEN1 IPR041 —
CACI 42 00A8h Level
 N/A N/A N/A IER05.IEN2 IPR042 —
SDACI 43 00ACh Level
 N/A N/A N/A IER05.IEN3 IPR043 —
