R01UH0823EJ0100 Rev.1.00 Page 560 of 1823

Jul 31, 2019

RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)

Figure 23.45 Example of Initial Output in Complementary PWM Mode (2)

MTU3.TCNT values

MTU4.TGRA

TDDR

MTU3.TCNT

MTU4.TCNT

Initial output

Time

Active level

MTU3.TCNT count start

(TSTR setting)

Complementary

PWM mode

(MTU3.TMDR

setting)

Positive-phase

output

Negative-phase

output

Timer output control register settings

TOCR1.OLSN bit = 0 (initial output: high; active level: low)

TOCR1.OLSP bit = 0 (initial output: high; active level: low)
