R01UH0823EJ0100 Rev.1.00 Page 608 of 1823

Jul 31, 2019

RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)

Figure 23.112 Example of Synchronous Clearing (When Condition 2 Applies)

MTU3.TGRA

TGR

TDDR

Positive-phase

output

Negative-phase

output

10 11 10 11

Initial output inhibition

: Dead time

Tb interval

Synchronous clearing

Although there is no period for output of the active level over this

interval, synchronous clearing leads to output of the active level.

MTU3.

TCNT

MTU4.

TCNT

Dead time is

eliminated.

Note: PWM output is active-low.
