Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 669 of 1823
Jul 31, 2019
RX23W Group 25. 16-Bit Timer Pulse Unit (TPUa)
x: Don’t care
Table 25.15 TPU2.TIOR
Bits IOB[3:0] Description
b7 b6 b5 b4 TPU2.TGRB Function TIOCB2 Pin (Function and Related Issue
0000Output compare register Output disabled
0001 Initial output is low output; low output at compare match
0010 Initial output is low output; high output at compare match
0011 Initial output is low output; toggle output at compare match
0100 Output disabled
0101 Initial output is high output; low output at compare match
0110 Initial output is high output; high output at compare match
0111 Initial output is high output; toggle output at compare match
1 x 0 0 Input capture register Capture input source is TIOCB2 pin; input capture at rising edge
1 x 0 1 Capture input source is TIOCB2 pin; input capture at falling edge
1 x 1 x Capture input source is TIOCB2 pin; input capture at both edges
