R01UH0823EJ0100 Rev.1.00 Page 830 of 1823

Jul 31, 2019

RX23W Group 30. Watchdog Timer (WDTA)

Figure 30.4 Operation Example in Auto-Start Mode

Refresh-

prohibited

period

Refresh-

prohibited

period

Refresh-

permitted

period

Status flag

cleared

Status flag

cleared

Counter value

100%

75%

50%

25%

RES# pin

Refresh

the counter

Active : H

REFEF flag

Active: High

UNDFF flag

Active: High

Reset output

from WDT

Active: High

Interrupt request

(WUNI)

Active: Low

Underflow

Counting starts

Refresh error Refresh error

Counting startsCounting startsCounting starts
