Xerox WorkCentre 7132 Service Documentation

January 2007
4-81
WorkCentre 7132
REP 11.3.2
Repairs/Adjustments
Reversion 4.0
Figure 4 Removing Lens Cover
7. Remove the IPS PWB Cover. (Figure 5)
1. Remove the screws (2).
2. Remove the IPS Cover.
Figure 5 Removing the IPS Cover
8. Disconnect the connectors (3). (Figure 6)
2
Remove the cover
1
Loosen the screws (6)
1
Remove the screws (2)
2
Remove the Cover
