January 2007
4-190
WorkCentre 7132
REP 16.12.2
Reversion 4.0
Repairs/Adjustments
Figure 9 Disconnecting the Connectors (3)
7. Remove the screws (4). (Figure 10)
Figure 10 removing the screws (4)
8. Pinch together the legs of the plastic PWB StandOffs to release the locking tabs (2). (Fig-
ure 11, Figure 12)
Disconnect the Connec-
tors (3)
Remove the screws (4)
