Xerox WorkCentre 7132 Service Documentation

January 2007
6-12
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
Chain 741-xxx Drive/MQ/NOHAD
740-084 FPGA Video Version 0 0~65535 R Version of FPGA Video Module
740-085 FPGA I/O Version 0 0~65535 R Version of FPGA I/O Module
Table 1 Chain 740-xxx IOT Manager
Chain-Link Name Default Range Read/Write Description
Table 2 Drive/MQ/NOHAD
Chain-Link Name Default Range Description
741-001 DRUM/IBT MOTOR HIGH PULSE 20 0~40 Fine Adjustment of Drum/IBT Motor speed (standard)
[Table No.]
741-002 DRUM/IBT MOTOR LOW PULSE 20 0~40 Fine Adjustment of Drum/IBT Motor speed (half speed)
[Table No.]
741-003 DRUM/IBT MOTOR REVERSE TIME 20 0~40 Drum/IBT Motor Reverse Rotation Time
[50msec]
741-004 MAIN MOTOR HIGH PULSE 9722 8736~1073
6
Fine Adjustment of Main Motor speed (standard)
[division ratio]
741-005 MAIN MOTOR LOW PULSE 19476 17474~214
74
Fine Adjustment of Main Motor speed (half speed)
[division ratio]
741-006 DEVE MOTOR PULSE 20 0~40 Fine Adjustment of DEVE Motor speed
[Table No.]
741-007 AUGER MOTOR PULSE 20 0~40 Fine Adjustment of Auger Motor speed
[Table No.]
741-008 FUSER FAN DELAY TIME 1 0~120 Fuser Fan's delay in turning Off.
[15sec]
741-009 REAR FAN DELAY TIME 1 0~120 Rear Fan's delay in turning Off.
[15sec]
741-011 DEW MODE TEMPERATURE OF POWERON 12 0~30 Dew Mode Threshold Temperature
[degree C]
741-012 DEW MODE TIME FOR POWERON 90 1~120 Dew Mode Time
[min]
741-013 FUSER FAN FAIL BYPASS 0 0~1 FUSER FAN FAIL Prevention
0: Normal Mode
1: FAN FAIL Prevention
741-014 REAR FAN FAIL BYPASS 0 0~1 REAR FAN FAIL Prevention
0: Normal Mode
1: FAN FAIL Prevention
741-015 DEODORANT FILTER SW 0 0~1 Sets whether or not Deodorant Filter is present.
0: No Deodorant Filter
1: Deodorant Filter present
741-016 DEW MODE TEMPERATURE OF PRINT 14 0~30 Dew Mode Threshold Temperature at the start of print
[degree C]
741-017 DEW MODE TIME FOR PRINT 60 15~180 How long Fan maintains its low-speed rotation in Dew Mode at the start of print
[sec]
741-018 DRUM MOTOR DELAY TIME 130 1~255 DRUM MOTOR's delay in turning OFF corresponding to FPOT
[10msec]
