Xerox WorkCentre 7132 Service Documentation

January 2007
6-13
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
Chain 742-xxx Paper Handling
741-019 MAIN MOTOR HIGH PULSE 9742 8736~1073
6
Fine Adjustment of Main Motor speed (standard/heavy 1)
[division ratio]
741-020 MAIN MOTOR HIGH PULSE 9742 8736~1073
6
Fine Adjustment of Main Motor speed (standard/label)
[division ratio]
741-021 MAIN MOTOR LOW PULSE 19476 17474~214
74
Fine Adjustment of Main Motor speed (half speed/heavy 2)
[division ratio]
741-022 MAIN MOTOR LOW PULSE 19476 17474~214
74
Fine Adjustment of Main Motor speed (half speed/label)
[division ratio]
741-023 MAIN MOTOR LOW PULSE 19476 17474~214
74
Fine Adjustment of Main Motor speed (half speed/transparency) [division ratio]
741-024 MAIN MOTOR LOW PULSE 19476 17474~214
74
Fine Adjustment of Main Motor speed (half speed/plain paper) [division ratio]
Table 2 Drive/MQ/NOHAD
Chain-Link Name Default Range Description
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
742-001 ROS Write Position (All) 0 -25~25 0.2mm RW Base Adjustment of Side Regi in fast scan direction (affects all the trays/paper
types/color modes)
742-002 ROS Write Position (Tray1/Plain Paper/Common) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Trays 1-3/plain paper/common)
742-003 ROS Write Position (Trays 1-3/heavy 1, coated 1/B) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Trays 1-3/heavy 1, coated 1/B)
742-004 ROS Write Position (Trays 1-3/heavy 1, coated 1/color) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Trays 1-3/heavy 1, coated 1/color)
742-005 ROS Write Position (Trays 1-3/heavy 2, coated 2/com-
mon)
0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Trays 1-3/heavy 2, coated 2/common)
742-006 ROS Write Position (Trays 1-3/label/B) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Trays 1-3/label/B)
742-007 ROS Write Position (Trays1-3/label/color) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Trays 1-3/label/color)
742-008 ROS Write Position (Trays 1-3/transparency/common) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Trays 1-3/transparency/common)
742-009 ROS Write Position (MSI/plain paper/common) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (MSI/plain paper/common)
742-010 ROS Write Position (MSI/heavy 1, coated 1/B) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (MSI/heavy 1, coated 1/B)
742-011 ROS Write Position (MSI/heavy 1, coated 1/color) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (MSI/heavy 1, coated 1/color)
742-012 ROS Write Position (MSI/heavy 2, coated 2/common) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (MSI/heavy 2, coated 2/common)
742-013 ROS Write Position (MSI/label/B) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (MSI/label/B)
742-014 ROS Write Position (MSI/label/color) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (MSI/label/color)
742-015 ROS Write Position (MSI/transparency/common) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (MSI/transparency/common)
742-016 ROS Write Position (Duplex All/plain paper/common) 0 -25~25 1ms RW Side Regi ADJ in fast scan direction (Duplex All/plain paper/common)
742-017 ROS Write Position (Duplex All/heavy 1, coated 1/B) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Duplex All/heavy 1, coated 1/B)
742-018 ROS Write Position (Duplex, feed from Tray 1/plain/com-
mon)
0 -25~25 0.2mm RW Side Regi ADJ in fast scan (Duplex, feed from Tray 1/plain paper/common)
742-019 ROS Write Position (Duplex, feed from Tray 2/plain/com-
mon)
0 -25~25 0.2mm RW Side Regi ADJ in fast scan (Duplex, feed from Tray 2/plain paper/common)
