Xerox WorkCentre 7132 Service Documentation

January 2007
6-14
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
742-020 ROS Write Position (Duplex, feed from Tray 3/plain/com-
mon)
0 -25~25 0.2mm RW Side Regi ADJ in fast scan (Duplex, feed from Tray 3/plain paper/common)
740-021 ROS Write Position (Duplex, feed from MSI/plain/com-
mon)
0 -25~25 0.2mm RW Side Regi ADJ in fast scan (Duplex, feed from MSI/plain paper/common)
742-022 ROS Write Position (Tray 2/plain paper/common) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan direction (Tray2/plain paper/common)
742-023 ROS Write Position (Tray 3/plain paper/common) 0 -25~25 0.2mm RW Side Regi in fast scan direction (Tray 3/plain paper/common)
742-024 ROS Write Position (whole Tray Module/plain/common) 0 -25~25 0.2mm RW Side Regi ADJ in fast scan (whole Tray Module/plain paper/common)
742-031 Timing of Starting Registration Operation (All) 56 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(affects all the trays/paper types/color modes)
742-032 Timing of Starting Registration Operation
(MSI/full speed/plain paper)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/full speed/plain paper)
742-033 Timing of Starting Registration Operation
(MSI/full speed/heavy 1)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/full speed/heavy 1)
742-034 Timing of Starting Registration Operation
(MSI/half speed/heavy 1)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/heavy 1, coated 1/color)
742-035 Timing of Starting Registration Operation
(MSI/half speed/heavy 2)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/half speed/heavy 2)
742-036 Timing of Starting Registration Operation
(MSI/full speed/label)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/full speed/label)
742-037 Timing of Starting Registration Operation
(MSI/half speed/label)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/half speed/label)
742-038 Timing of Starting Registration Operation
(MSI/half speed/transparency)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/half speed/transparency)
742-039 Timing of Starting Registration Operation
(Trays 1-3/full speed/plain paper)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/full speed/plain paper)
742-040 Timing of Starting Registration Operation
(Trays 1-3/full speed/heavy 1)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/full speed/heavy 1)
742-041 Timing of Starting Registration Operation
(Trays 1-3/half speed/heavy 1)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/half speed/heavy 1)
742-042 Timing of Starting Registration Operation
(Trays 1-3/half speed/heavy 2)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/half speed/heavy 2)
742-043 Timing of Starting Registration Operation
(Trays 1-3/full speed/label)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/full speed/label)
742-044 Timing of Starting Registration Operation
(Trays 1-3/half speed/label)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/half speed/label)
742-045 Timing of Starting Registration Operation
(Trays 1-3/half speed/transparency)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/transparency/common)
742-046 Timing of Starting Registration Operation
(Duplex/full speed/plain paper)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Duplex/full speed/plain paper)
742-047 Timing of Starting Registration Operation
(Duplex/full speed/heavy 1)
80 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Duplex/full speed/heavy 1)
742-048 Timing of Starting Registration Operation
(MSI/half speed/plain paper)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(MSI/half speed/plain paper)
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
