Xerox WorkCentre 7132 Service Documentation

January 2007
6-15
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
742-049 Timing of Starting Registration Operation
(Trays 1-3/half speed/plain paper)
92 0~160 1mc RW Base Adjustment of Lead Regi in slow scan direction
(Trays 1-3/half speed/plain paper)
742-055 Timing of Starting MSI Feed Control (MSI/full speed/plain)
(‘PH standard signal’ to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting MSI Feed (full speed/plain paper)
742-056 Timing of Starting MSI Feed Control (MSI/full speed/non-
plain)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting MSI Feed (full speed/any other than plain paper)
742-057 Timing of Starting MSI Feed Control (MSI/half speed/
plain)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting MSI Feed (half speed/plain paper)
742-058 Timing of Starting MSI Feed Control (MSI/half speed/non-
plain)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting MSI Feed (half speed/except plain paper)
742-059 Timing of Starting Tray Feed Control (Tray 1/full speed/B/
8.5x11LEF-G)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (full speed/B/8.5x11LEF-G)
742-060 Timing of Starting Tray Feed Control (Tray 1/full speed/B/
A4SEF-G~11x17SEF-G)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (full speed/B/A4SEF-G to 11x17SEF-
G)
742-061 Timing of Starting Tray Feed Control (Tray 1/full/color/side
A)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (full speed/color/side A)
742-062 Timing of Starting Tray Feed Control (Tray 1/full/color/side
B)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (full speed/color/side B)
742-063 Timing of Starting Tray Feed Control (Tray 1/half speed/
except transparency/B/8.5x11LEF-G)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/except transparency/B/
8.5x11LEF-G)
742-064 Timing of Starting Tray Feed Control (Tray 1/half speed/
except transparency/B/A4SEF-G~11x17SEF-G)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/except transparency/B/
A4SEF-G to 11x17SEF-G)
742-065 Timing of Starting Tray Feed Control (Tray 1/half speed/
except transparency/color/side A)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/except transparency/
color/side A)
742-066 Timing of Starting Tray Feed Control (Tray 1/half speed/
except transparency/color/side B)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/except transparency/
color/side B)
742-067 Timing of Starting Tray Feed Control (Tray 1/half speed/
transparency/B/side A)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/transparency/B/side A)
742-068 Timing of Starting Tray Feed Control (Tray 1/half speed/
transparency/B/side B)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/transparency/B/side B)
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
