Xerox WorkCentre 7132 Service Documentation

January 2007
6-16
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
742-069 Timing of Starting Tray Feed Control (Tray 1/half speed/
transparency/color/side A)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/transparency/color/side
A)
742-070 Timing of Starting Tray Feed Control (Tray 1/half speed/
transparency/color/side B)
(“PH standard signal” to Feed Start)
10 -100~100 2ms RW Adjusts the timing of starting Tray 1 Feed (half speed/transparency/color/side
B)
742-071 Timing of Starting Tray Feed Control (2TM Tray 2/full
speed/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 2ms RW Adjustment of Start Feed signal (2TM Tray 2)
742-072 Timing of Starting Tray Feed Control (2TM Tray 2/full
speed/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-073 Timing of Starting Tray Feed Control (2TM Tray 2/full
speed/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-074 Timing of Starting Tray Feed Control (2TM Tray 2/full
speed/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-075 Timing of Starting Tray Feed Control (2TM Tray 2/half
speed/except transparency/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-076 Timing of Starting Tray Feed Control (2TM Tray 2/half
speed/except transparency/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-077 Timing of Starting Tray Feed Control (2TM Tray 2/half
speed/except transparency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-078 Timing of Starting Tray Feed Control (2TM Tray 2/half
speed/except transparency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-079 Timing of Starting Tray Feed Control (2TM Tray 2/trans-
parency/B/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-080 Timing of Starting Tray Feed Control (2TM Tray 2/trans-
parency/B/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-081 Timing of Starting Tray Feed Control (2TM Tray 2/trans-
parency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-082 Timing of Starting Tray Feed Control (2TM Tray 2/trans-
parency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-083 Timing of Starting Tray Feed Control (TTM Tray 2/full
speed/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 2ms RW Start Feed signal Adjustment (TTM Tray 2)
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
