Page #1340 background image
January 2007
6-17
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
742-084 Timing of Starting Tray Feed Control (TTM Tray 2/full
speed/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-085 Timing of Starting Tray Feed Control (TTM Tray 2/full
speed/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-086 Timing of Starting Tray Feed Control (TTM Tray 2/full
speed/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-087 Timing of Starting Tray Feed Control (TTM Tray 2/half
speed/except transparency/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-088 Timing of Starting Tray Feed Control (TTM Tray 2/half
speed/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-089 Timing of Starting Tray Feed Control (TTM Tray 2/half
speed/except transparency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-090 Timing of Starting Tray Feed Control (TTM Tray 2/half
speed/except transparency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-091 Timing of Starting Tray Feed Control (TTM Tray 2/trans-
parency/B/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-092 Timing of Starting Tray Feed Control (TTM Tray 2/trans-
parency/B/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-093 Timing of Starting Tray Feed Control (TTM Tray 2/trans-
parency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-094 Timing of Starting Tray Feed Control (TTM Tray 2/trans-
parency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-095 Timing of Starting Tray Feed Control (2TM Tray 3/full
speed/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 2ms RW Start Feed signal Adjustment (2TM Tray 3)
742-096 Timing of Starting Tray Feed Control (2TM Tray 3/full
speed/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-097 Timing of Starting Tray Feed Control (2TM Tray 3/full
speed/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-098 Timing of Starting Tray Feed Control (2TM Tray 3/full
speed/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
