January 2007
6-18
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
742-099 Timing of Starting Tray Feed Control (2TM Tray 3/half
speed/except transparency/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-100 Timing of Starting Tray Feed Control (2TM Tray 3/half
speed/except transparency/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-101 Timing of Starting Tray Feed Control (2TM Tray 3/half
speed/except transparency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-102 Timing of Starting Tray Feed Control (2TM Tray 3/half
speed/except transparency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-103 Timing of Starting Tray Feed Control (2TM Tray 3/trans-
parency/B/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-104 Timing of Starting Tray Feed Control (2TM Tray 3/trans-
parency/B/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-105 Timing of Starting Tray Feed Control (2TM Tray 3/trans-
parency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-106 Timing of Starting Tray Feed Control (2TM Tray 3/trans-
parency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-107 Timing of Starting Tray Feed Control (TTM Tray 3/full
speed/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 2ms RW Start Feed signal Adjustment (TTM Tray 3)
742-108 Timing of Starting Tray Feed Control (TTM Tray 3/full
speed/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-109 Timing of Starting Tray Feed Control (TTM Tray 3/full
speed/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-110 Timing of Starting Tray Feed Control (TTM Tray 3/full
speed/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-111 Timing of Starting Tray Feed Control (TTM Tray 3/half
speed/except transparency/B/8.5x11LEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-112 Timing of Starting Tray Feed Control (TTM Tray 3/half
speed/B/A4SEF-G~11x17SEF-G)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-113 Timing of Starting Tray Feed Control (TTM Tray 3/half
speed/except transparency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
