Xerox WorkCentre 7132

January 2007
6-19
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
742-114 Timing of Starting Tray Feed Control (TTM Tray 3/half
speed/except transparency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-115 Timing of Starting Tray Feed Control (TTM Tray 3/trans-
parency/B/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-116 Timing of Starting Tray Feed Control (TTM Tray 3/trans-
parency/B/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-117 Timing of Starting Tray Feed Control (TTM Tray 3/trans-
parency/color/side A)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-118 Timing of Starting Tray Feed Control (TTM Tray 3/trans-
parency/color/side B)
(Start Feed signal to Regi Clutch On signal)
10 -100~100 RW ditto
742-119 Tray1 Feed Off Timing (full speed)
(From #1 Feed Out Snr On)
0 -10~10 10ms RW Adjusts the timing of turning Off Feed Motor after #1 Feed Out SNR ON
(full speed)
742-120 Tray 1 Feed Off Timing (half speed)
(From #1 Feed Out Snr On)
0 -20~20 10ms RW Adjusts the timing of turning Off Feed Motor after #1 Feed Out SNR ON
(half speed)
742-136 T/A CL ON Timing at Feed Adjustment (full speed)
(Start MSI Feed signal)
0 -5~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from MSI.
(full speed)
742-137 T/A CL ON Timing at Feed Adjustment (half speed)
(Start MSI Feed signal)
0 -10~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from MSI.
(half speed)
742-138 T/A CL ON Timing at Feed Adjustment (full speed)
(from Start #1Feed signal)
0 -15~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from Tray 1.
(full speed)
742-139 T/A CL ON Timing at Feed Adjustment (half speed)
(from Start #1Feed signal)
0 -5~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from Tray 1.
(half speed)
742-140 T/A CL ON Timing at Feed Adjustment (full speed)
(from Start 2TM #2 Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from 2TM Tray 2.
(full speed)
742-141 T/A CL ON Timing at Feed Adjustment (half speed)
(from Start 2TM #2 Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from 2TM Tray 2
(half speed)
742-142 T/A CL ON Timing at Feed Adjustment (full speed)
(from Start 2TM #3 Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from 2TM Tray 3
(full speed)
742-143 T/A CL ON Timing at Feed Adjustment (half speed)
(from Start 2TM #3 Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from 2TM Tray 3
(half speed)
742-144 T/A CL ON Timing at Feed Adjustment (full speed)
(from Start TTM #2 Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from TTM Tray 2
(full speed)
742-145 T/A CL ON Timing at Feed Adjustment (half speed)
(from Start TTM # 2Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from TTM Tray 2
(half speed)
742-146 T/A CL ON Timing at Feed Adjustment (full speed)
(from Start TTM #3 Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from TTM Tray 3
(full speed)
742-147 T/A CL ON Timing at Feed Adjustment (half speed)
(from Start TTM #3 Feed signal)
0 -20~20 10ms RW Adjusts the timing of connecting Take Away Clutch after feed from TTM Tray 3
(half speed)
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
