Xerox WorkCentre 7132

January 2007
6-20
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
742-148 T/A CL OFF Timing at Regi Loop Formation (MSI/full
speed/plain paper)
RegiSnrOn to TA Clutch Off
-6 -100~100 2ms RW Loop Amount Adjustment (MSI/full speed/plain paper)
742-149 T/A CL OFF Timing at Regi Loop Formation (MSI/full
speed/heavy 1)
RegiSnrOn to TA Clutch Off
-13 -100~100 2ms RW Loop Amount Adjustment (MSI/full speed/heavy 1)
742-150 T/A CL OFF Timing at Regi Loop Formation (MSI/half
speed/heavy 1)
RegiSnrOn to TA Clutch Off
-25 -100~100 2ms RW Loop Amount Adjustment (MSI/half speed/heavy 1)
742-151 T/A CL OFF Timing at Regi Loop Formation (MSI/half
speed/heavy 2)
RegiSnrOn to TA Clutch Off
-25 -100~100 2ms RW Loop Amount Adjustment (MSI/half speed/heavy 2)
742-152 T/A CL OFF Timing at Regi Loop Formation (MSI/full
speed/label)
RegiSnrOn to TA Clutch Off
-19 -100~100 2ms RW Loop Amount Adjustment (MSI/full speed/label)
742-153 T/A CL OFF Timing at Regi Loop Formation (MSI/half
speed/label)
RegiSnrOn to TA Clutch Off
-38 -100~100 2ms RW Loop Amount Adjustment (MSI/half speed/label)
742-154 T/A CL OFF Timing at Regi Loop Formation (MSI/half
speed/transparency)
RegiSnrOn to TA Clutch Off
-13 -100~100 2ms RW Loop Amount Adjustment (MSI/half speed/transparency)
742-155 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/full
speed/plain paper)
RegiSnrOn to TA Clutch Off
0 -100~100 2ms RW Loop Amount Adjustment (Trays 1-3/full speed/plain paper)
742-156 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/full
speed/heavy 1)
RegiSnrOn to TA Clutch Off
0 -100~100 2ms RW Loop Amount Adjustment (Trays 1-3/full speed/heavy 1)
742-157 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/
half speed/heavy 1)
RegiSnrOn to TA Clutch Off
0 -100~100 2ms RW Loop Amount Adjustment (Trays 1-3/half speed/heavy 1)
742-158 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/
half speed/heavy 2)
RegiSnrOn to TA Clutch Off
-24 -100~100 2ms RW Loop Amount Adjustment (Trays1-3/half speed/heavy 2)
742-159 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/full
speed/label)
RegiSnrOn to TA Clutch Off
-6 -100~100 2ms RW Loop Amount Adjustment (Trays 1-3/full speed/label)
742-160 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/
half speed/label)
RegiSnrOn to TA Clutch Off
-13 -100~100 2ms RW Loop Amount Adjustment (Trays 1-3/half speed/label)
742-161 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/
half speed/transparency)
RegiSnrOn to TA Clutch Off
0 -100~100 2ms RW Loop Amount Adjustment (Trays 1-3/half speed/transparency)
742-162 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/full
speed/plain paper)
(RegiClutchOn signal to TA Clutch On)
0 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON (Trays
1-3, MSI/full speed/plain paper)
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
