Xerox WorkCentre 7132

January 2007
6-21
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
742-163 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/full
speed/heavy 1)
(RegiClutchOn signal to TA Clutch On)
0 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON (Trays
1-3, MSI/full speed/heavy 1)
742-164 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/half
speed/heavy 1)
(RegiClutchOn signal to TA Clutch On)
0 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON (Trays
1-3, MSI/half speed/heavy 1)
742-165 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/half
speed/heavy 2)
(RegiClutchOn signal to TA Clutch On)
0 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON (Trays
1-3, MSI/half speed/heavy 2)
742-166 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/full
speed/label)
(RegiClutchOn Signal ~TA Clutch On)
13 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON (Trays
1-3, MSI/full speed/label)
742-167 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/half
speed/label)
(RegiClutchOn signal to TA Clutch On)
25 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON (Trays
1-3, MSI/half speed/label)
742-168 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/half
speed/transparency)
(RegiClutchOn signal to TA Clutch On)
0 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON
(Trays1-3, MSI/half speed/transparency)
742-169 T/A CL OFF Timing (full speed/B)
(From RegiSnrOff)
0 -50~100 1ms RW Adjusts the timing of stopping Take Away Clutch after Regi projection (full
speed/B)
742-170 T/A CL OFF Timing (full speed/color)
(From RegiSnrOff)
0 -50~100 1ms RW Adjusts the timing of stopping Take Away Clutch after Regi projection (full
speed/color)
742-171 T/A CL OFF Timing (half speed/B)
(From RegiSnrOff)
0 -50~100 1ms RW Adjusts the timing of stopping Take Away Clutch after Regi projection (half
speed/B)
742-172 T/A CL OFF Timing (half speed/color)
(From RegiSnrOff)
0 -50~100 1ms RW Adjusts the timing of stopping Take Away Clutch after Regi projection (half
speed/color)
742-175 T/A CL OFF Timing at Regi Loop Formation (MSI/half
speed/plain paper)
RegiSnrOn to TA Clutch Off
-13 -100~100 2ms RW Loop Amount Adjustment (MSI/half speed/plain paper)
742-176 T/A CL OFF Timing at Regi Loop Formation (Trays 1-3/
half speed/plain paper)
RegiSnrOn to TA Clutch Off
0 -100~100 2ms RW Loop Amount Adjustment (Trays 1-3/half speed/plain paper)
742-179 T/A CL ON Timing at Regi Projection (Trays 1-3, MSI/half
speed/plain paper) (Regi Clutch On signal to TA Clutch
On)
0 0~200 1ms RW Adjusts the timing of connecting Take Away Clutch after Regi Clutch ON (Trays
1-3,MSI/half speed/plain paper)
742-181 [TM] TA Clutch ON Timing (2TM)-in Full Speed mode 0 -75~75 2ms RW Adjusts time from Feed to the start of TA Clutch ON.
742-182 [TM] TA Clutch ON Timing (2TM)
-half speed/except transparency
0 -75~75 RW ditto
742-183 [TM] TA Clutch ON Timing (2TM)
-half speed/in Transparency mode
0 -25~75 RW ditto
742-184 [TM] TA Clutch ON Timing (TTM-Tray 2)
-in Full Speed mode
0 -75~75 RW ditto
742-185 [TM] TA Clutch ON Timing (TTM-Tray 2)
-half speed/except transparency
0 -75~75 RW ditto
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
