January 2007
6-22
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
742-186 [TM] TA Clutch ON Timing (TTM-Tray2)
-half speed/in Transparency mode
0 -75~75 RW ditto
742-187 [TM] TA Clutch ON Timing (TTM-Tray 3)
-in Full Speed mode
0 -75~75 RW ditto
742-188 [TM] TA Clutch ON Timing (TTM-Tray3)
-half speed/except Transparency
0 -75~75 RW ditto
742-189 [TM] TA Clutch ON Timing (TTM-Tray3)
-half speed/in Transparency mode
0 -75~75 RW ditto
742-190 [TM] TA Clutch OFF Timing (TM) at Arrival at Regi
-in Full Speed mode
0 -100~100 2ms RW Adjusts time from F/O Snr #2 On to the start of TA Clutch Off.
(Control of post-T/A pushing)
742-191 [TM] TA Clutch OFF Timing (TM) at Arrival at Regi
-in Half Speed mode
0 -100~100 RW ditto
742-192 [TM] Feed Stop OFF Timing (post-Regi pushing)
-in Full Speed mode
0 0~30 1ms RW Adjusts time from Regi Clutch On (Feed Stop) to the start of TA Clutch On.
(Clearance of post-T/A pushing)
742-193 [TM] Feed Stop OFF Timing (post-Regi pushing)
-in Half Speed mode
0 0~30 RW ditto
742-194 [TM] Wait TA Clutch OFF Timing(2TM)
-in Full Speed mode
35 1~69 1ms RW Adjusts time from F/O Snr On to the start of TA Clutch Off.
(Control of temporarily stopping T/A)
742-195 [TM] Wait TA Clutch OFF Timing(2TM)
-in Half Speed mode
85 25~145 RW ditto
742-196 [TM] Wait TA Clutch OFF Timing(TTM)
-in Full Speed mode
30 2~60 RW ditto
742-197 [TM] Wait TA Clutch OFF Timing(TTM)
-in Half Speed mode
75 15~135 RW ditto
742-198 Feed Stop OFF Timing (no preceding paper/2TM Tray 2)
-in Full Speed mode
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-199 Feed Stop OFF Timing (no preceding paper/2TM Tray 2)
-half speed/except transparency/B
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-200 Feed Stop OFF Timing (no preceding paper/2TM Tray 2)
-half speed/except transparency/color
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-201 Feed Stop OFF Timing (no preceding paper/2TM Tray 2)
-in Half Speed and Transparency mode
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON. (Clearance of tem-
porarily stopping T/A)
ADJ Unit: 1[ms/step]
742-202 Feed Stop OFF Timing (no preceding paper/2TM Tray 3)
-in Full Speed mode
0 -100~100 1ms RW Adjusts time Tray 3 Feed to the start of TA Clutch ON. (Clearance of tempo-
rarily stopping T/A)
ADJ Unit: 1[ms/step]
742-203 Feed Stop OFF Timing (no preceding paper/2TM Tray 3)
-half speed/except transparency/B
0 -100~100 1ms RW Adjusts time from Tray 3 Feed to the start of TA Clutch ON (Clearance of tem-
porarily stopping T/A)
1[ms/step] adjustment
742-204 Feed Stop OFF Timing (no preceding paper/2TM Tray 3)
-half speed/except transparency/color
0 -100~100 1ms RW Adjusts Tray 3 Feed to the start of TA Clutch ON. (Clearance of temporarily
stopping T/A)
ADJ Unit: 1[ms/step]
742-205 Feed Stop OFF Timing (no preceding paper/2TM Tray 3)
-in Half Speed and Transparency mode
0 -100~100 1ms RW Adjusts Tray 3 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
