IOT NVM List
General procedures information
Reversion 4.0
742-206 Feed Stop OFF Timing (no preceding paper/TTM Tray 2)
-in Full Speed mode
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-207 Feed Stop OFF Timing (no preceding paper/TTM Tray 2)
-half speed/except transparency/B
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-208 Feed Stop OFF Timing (no preceding paper/TTM Tray 2)
-half speed/except transparency/color
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-209 Feed Stop OFF Timing (no preceding paper/TTM Tray 2)
-in Half Speed and Transparency mode
0 -100~100 1ms RW Adjusts time from Tray 2 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-210 Feed Stop OFF Timing (no preceding paper/TTM Tray 3)
-in Full Speed mode
0 -100~100 1ms RW Adjusts time from Tray 3 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-211 Feed Stop OFF Timing (no preceding paper/TTM Tray 3)
-half speed/except transparency/B
0 -100~100 1ms RW Starts time from Tray 3 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-212 Feed Stop OFF Timing (no preceding paper/TTM Tray 3)
-half speed/except transparency/color
0 -100~100 1ms RW Adjusts time from Tray 3 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-213 Feed Stop OFF Timing (no preceding paper/TTM Tray 3)
-in Half Speed and Transparency mode
0 -100~100 1ms RW Adjusts time from Tray 3 Feed to the start of TA Clutch ON.
(Clearance of temporarily stopping T/A)
742-231 Timing of Stopping Registration Operation
-full speed
76 0~246 1ms RW Adjusts the timing of stopping Regi Clutch after Regi projection.
(full speed)
742-232 Timing of Stopping Registration Operation
-half speed
76 0~246 2ms RW Adjusts the timing of stopping Regi Clutch after Regi projection
(half speed)
742-233 Size-in-Feed-direction Detection Coefficient T1 0 -20~20 2ms RW Adjusts the parameter in the formula for detecting a size in feed direction
742-236 Paper Inverting Operation
Timing of Stopping Forward Rotation (full speed/plain
paper)
60 0~200 1ms RW Adjusts the timing of stopping the forward rotation to invert the paper after
paper turns Off Exit Sensor 1. (plain paper)
742-237 Paper Inverting Operation
Timing of Stopping Forward Rotation (full speed/heavy 1)
60 0~200 1ms RW Adjusts the timing of stopping the forward rotation to invert the paper after
paper turns Off Exit Sensor 1. (heavy 1)
742-238 Paper Inverting Operation
Timing of Starting Reverse Rotation (L<=216/Exit1)
100 0~200 1ms RW Adjusts the timing of starting to invert paper after Regi Clutch On for it. The
paper waiting to be inverted is small-sized and will be output from Exit 1.
742-239 Paper Inverting Operation
Timing of Starting Reverse Rotation (L<=216/Exit2, Side
Tray)
100 0~200 1ms RW Adjusts the timing of starting to invert paper after Regi Clutch On for it. The
paper waiting to be inverted is small-sized and will be output from Exit 2/Side
Tray.
742-240 Paper Inverting Operation
Timing of Adjusting Regi Loop (plain paper/L>216)
64 0~164 1ms RW Adjusts the timing of stopping Exit Motor after Regi Sensor ON, in correcting
and controlling Duplex Regi Feed. (plain paper)
742-241 Paper Inverting Operation
Timing of Adjusting Regi Loop (heavy 1/L>216)
64 0~164 1ms RW Adjusts the timing of stopping Exit Motor after Regi Sensor ON, in correcting
and controlling Duplex Regi Feed. (heavy 1)
742-242 Paper Inverting Operation
Timing of Starting Post-Regi Pushing (plain paper/L>216)
0 0~200 1ms RW Adjusts time from Regi Projection to Exit Motor On, in correcting and controlling
Duplex Post-Regi-Projection Pushing. (plain paper)
742-243 Paper Inverting Operation
Timing of Starting Post-Regi Pushing (heavy 1/L>216)
0 0~200 1ms RW Adjusts time from Regi Projection to Exit Motor On, in correcting and controlling
Duplex Post-Regi-Projection Pushing (heavy 1)
742-244 Timing of Starting Duplex Transporting Operation (full
speed)
30 0~60 10ms RW Timing of turning On Duplex Motor to pull in paper to invert it
(Exit2 Motor CCW On to Duplex Motor On)
ADJ Unit: 10 [ms/step]
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
