WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
Chain 744-xxx FUSER
742-307 OHP Sensor PWM Step 1 1~30 0.1% RW Adjusts in steps of what amount OHP Sensor PWM Output should be
decreased.
742-308 Timing of Starting Paper Type Detection (full speed) 95 0~255 1ms RW Timing of starting paper type detection after Regi Clutch ON (full speed)
742-309 Timing of Starting Paper Type Detection (half speed) 95 0~255 2ms RW Timing of starting paper type detection after Regi Clutch ON (half speed)
742-310 Threshold for Judging Paper Type 620 0~1023 1 RW Adjusts threshold used to judge paper to be transparent in paper type detection.
742-311 OHP Sensor Fail Judgment Value 125 0~200 0.5% RW Adjusts, in OHP correction operation, value used to judge from OHP PWM out-
put that OHP Sensor failed.
742-312 Timing of Detecting OHP Sensor Fail 40 0~90 10ms RW Adjusts the timing of trying to detect OHP Sensor Fail.
742-314 OHP Sensor Standard Value Adjustment Range 20 1~250 0.1% RW Value used to adjust standard value in OHP correction operation
742-319 No Paper Run & Jam Bypass 0 0~15 RW 0: Normal mode
1: Jam Bypass
2: No Paper Run
3: Check IBT
742-320 Selecting where to output Test Print 0 0~4 RW Switch where to output Test Print
0: Face Down Tray #1 / Finisher Stacker
1: Face Down Tray #2
2: Face Up Tray
742-321 Selecting whether/how to offset-output Test Print 0 0~2 RW Offset selection
0: No Offset
1: Front Offset
2: Rear Offset
Applies only when Output Tray is Face Down Tray #2
742-322 Component Control Feed /Lift Up Motor Speed
(all the trays)
17 0~17 RW Specifies the speed of Feed/Lift Up Motor in Component Control.
742-323 Pre Feed SNR ON Jam Timer (all the trays) 0 -20~20 10ms RW Jam Timer Value Adjustment
742-324 Feed Out SNR ON Jam Timer (all the trays) 0 -30~30 10ms RW Jam Timer Value Adjustment
Table 3 Paper Handling
Chain-Link Name Default Range
Step
(mm)
Read/
Write Description
Table 4 Fuser
Chain-Link Name Default Range Step
Read/
Write
Description
744-001 Control Temperature in Low Power Mode 140 0~200 1 deg C RW Target temperature of NCS-Center in Low Power Mode
744-004 Failure Detection Flag 0 0~3 RW 0: Normal
1: Abnormal high temp of NCS-Center detected
2: Abnormal high temp of STS-Front detected
3: Abnormal temp of NCS/STS
744-005 Abnormal-Amplified-Difference Detection Flag 0 0~1 RW 0: Normal
1: Abnormal amplified difference detected
744-008 Ready Temperature 1 150 100~200 1 deg C RW
744-009 Ready Temperature 2 165 100~200 1 deg C RW
744-010 Standby Temperature 175 100~200 1 deg C RW
