Xerox WorkCentre 7132 Service Documentation

January 2007
6-84
WorkCentre 7132
IIT NVM List
Reversion 4.0
General procedures information
715-551 Color Copy at during AE
BGR-AE Adjustment Level (Text/Photo)
0 0~4095 Value (0~15) x 3 = Erase Amount (8bit conversion)
(x12 for 10bit conversion)
Lower digits 0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
715-552 BW Copy during AE
BGR-AE Adjustment Level (Text)
0 0~4095 Value (0~15) x 3 = Erase Amount (8bit conversion)
(x12 for 10bit conversion)
Lower digits 0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
715-553 Color Copy at during AE
BGR-AE Adjustment Level (Text)
0 0~4095 Value (0~15) x 3 = Erase Amount (8bit conversion)
(x12 for 10bit conversion)
Lower digits 0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
715-554 BW ContoneScan during AE
BGR-AE Adjustment Level (Text/Photo)
0 0~4095 Value (0~15) x 3 = Erase Amount (8bit conversion)
(x12 for 10bit conversion)
Lower digits 0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
715-555 Color ContoneScan during AE
BGR-AE Adjustment Level (Text/Photo)
0 0~4095 Value (0~15) x 3 = Erase Amount (8bit conversion)
(x12 for 10bit conversion)
Lower digits 0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
715-600 AE1 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At SMPST, SMPED setting
715-601 AE2 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At SMPST, SMPED setting
715-602 AE3 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At MAEFST, MAEFSE setting (* Area
used as detection area is used for PreIPS noise removal as well)
715-603 AE4 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At SMPST, SMPED setting
715-604 Line to Fix Variation 60 0~65535 High Speed AE/Slow Scan Direction variable fixed position/NCON, Slow Scan Edge AE Detection
Amount (0.16mm increments)
715-605 HAE Line to Fix Variation 240 0~65535 High Speed AE/Slow Scan Direction End position, Slow Scan Edge AE Detection Amount HAESSE
715-606 MAE Line to Fix Variation 240 0~65535 High Speed AE/Slow Scan Direction End position, Slow Scan Edge AE Detection Amount MAESSE
715-607 NAE Line to Fix Variation 240 0~65535 High Speed AE/Slow Scan Direction End position, Slow Scan Edge AE Detection Amount NAESSE
715-608 Variation Control for BW Copy 1 0~1 LIM Control mode
715-609 Variation Control for Color Copy 1 0~1 LIM Control mode
715-610 Variation Control for FAX, BinScan 1 0~1 LIM Control mode
715-611 Variation Control for ContoneScan 1 0~1 LIM Control mode
715-612 Background Color Suppression Threshold Value
(HAE)
127 0~255 HAE Histogram threshold value Specify using 100/255% increments. HAETH
715-613 Background Color Suppression Threshold Value
(NAE1)
33 0~255 NAE Block Count Threshold (Color Block Count Threshold) Set in 100/255% increments. NAEBLK-
THC
715-614 Background Color Suppression Threshold Value
(NAE2)
204 0~255 NAE Block Count Threshold (Specified Color Block threshold value) Set in 100/255% increments.
NAEBLKTHY
Table 3 IISS
Chain-Link Content Default Range Meaning
