Xerox WorkCentre 7132

January 2007
6-155
WorkCentre 7132
Controller & Fax NVM List
General procedures information
Reversion 4.0
825-161 CED Send Frequency: CED signal fre-
quency.
0~1 1: 2100Hz Read/Write 0: 1080Hz, 1: 2100Hz
825-162 T1 Timer Value at Receive mode 1~90 39sec Read/Write 1~90 (sec)
825-163 Timer Value of no tone timing recom-
mended in T.30
0~1 0: 75msec Read/Write 0: 75msec, 1sec
825-164 FSK detection before image information is
received (To be referred to at Non-ECM)
0~1 1: Detect Read/Write 0: Do not detect, 1: Detect
825-165 FSK detection before image information is
received
0~1 0: Do not detect Read/Write 0: Do not detect, 1: Detect
825-166 G3M CSI Send CSI: Notification signal to
the Sender of the ID Code registered at the
Receiver.
0~1 0: Transmit Read/Write 0: Transmit, 1: OFF
825-168 Sending of Local Name 0~1 1: ON Read/Write 0: OFF, 1: ON
825-169 To determine resending of the Local Name 0~1 0: Do not resend Read/Write 0: Do not resend, 1: Resend
825-170 ECM Frame Size (The frame is configured
from the pixels which are divided into 8 bits
for every 1mm)
0~1 0: 256bytes Read/Write 0: 256 bytes, 1: 64 bytes
825-171 G3M ECM T5 Timer (2 channel common)
Timer to the RNR Signal sent out when
memory overflow etc. occurs at the
Receiver, or when continuous receiving is
not possible.
0~2 0: 1 (min) Read/Write 0: 1 (min), 1: 3 (min), 2: No limit
825-173 Send Reference of RTN Command (Pro-
portion) RTN: The message is not received
properly, indicating that Training is neces
-
sary.
0~3 0: 5% Read/Write 0: 5%, 1: 10%, 2: 15%, 3: 20%
825-174 Send Reference of RTN Command (No. of
Continuous Lines)
0~3 2: 6line, Read/Write 0: No limit, 1: 3line, 2: 6line, 3: 12line
825-175 No. of bytes of the DIS/DTC FIF Sending
(DTC: Send command in response to DIS)
0~1 0: No limit Read/Write 0: No limit, 1: 4bytes System
825-176 ECM Capability (Auto Error Resending fea-
ture): A feature to start resending when an
error has been repaired during transmis
-
sion. (For International communication)
0~1 1: Enable Read/Write 0: Disable, 1: Enable
825-177 CCITT Trellis Capability On/Off and types 0~2 2: V.17 or later Read/Write 0: V.27 or later, 1: V.29 or later, 2: V.17 or later
825-178 CCITT Trellis Capability On/Off and types
(Used in International Communication)
0~2 2: V.17 or later Read/Write 0: V.27 or later, 1: V.29 or later, 2: V.17 or later
825-179 Ch0 ECM Block Synchronize 0~2 0: 200ms Read/Write 0: 200 ms, 1: 500 ms, 2: 1 sec
825-180 ECM Block Synchronize for Ch1 0~2 0: 200ms Read/Write 0: 200 ms, 1: 500 ms, 2: 1 sec,
825-181 ECM Block Synchronize for Ch2 0~2 0: 200ms Read/Write 0: 200 ms, 1: 500 ms, 2: 1 sec,
825-182 ECM Block Synchronize for Ch3 0~2 0: 200ms Read/Write 0: 200 ms, 1: 500 ms, 2: 1 sec,
825-183 ECM Block Synchronize for Ch4 0~2 0: 200ms Read/Write 0: 200 ms, 1: 500 ms, 2: 1 sec
825-184 ECM Block Synchronize for Ch5 0~2 0: 200ms Read/Write 0: 200 ms, 1: 500 ms, 2: 1 sec,
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
