Xerox WorkCentre 7132

January 2007
6-157
WorkCentre 7132
Controller & Fax NVM List
General procedures information
Reversion 4.0
825-198 G3 DIS ignore for Channel 1 (No. of DIS
ignored)
0~1 0: Ignore DIS Read/Write 0: Ignore DIS 1: Ignore DIS once
825-199 G3 DIS ignore for Channel 2 (No. of DIS
ignored)
0~1 0: Ignore DIS Read/Write 0: Ignore DIS 1: Ignore DIS once
825-200 G3 DIS ignore for Channel 3 (No. of DIS
ignored)
0~1 0: Ignore DIS Read/Write 0: Ignore DIS 1: Ignore DIS once
825-201 G3 DIS ignore for Channel 4 (No. of DIS
ignored)
0~1 0: Ignore DIS Read/Write 0: Ignore DIS 1: Ignore DIS once
825-202 G3 DIS ignore for Channel 5 (No. of DIS
ignored)
0~1 0: Ignore DIS Read/Write 0: Ignore DIS 1: Ignore DIS once
825-203 Channel 0 G3 ECM EOR_Q Command
(EOR: Stops resending by the signal capa
-
ble of transmission for every 3 times of
resending)
0~1 1: Continue Read/Write 0: Stop, 1: Continue
825-209 G3 Modem Mode for Ch0 0~1 1: Auto Read/Write 0: CCITT G3, 1: Auto
825-210 G3 Modem Mode For Ch1 0~1 1: Auto Read/Write 0: CCITT G3, 1: Auto
825-211 G3 Modem Mode For Ch 2 0~1 1: Auto Read/Write 0: CCITT G3, 1: Auto
825-212 G3 Modem Mode For Ch 3 0~1 1: Auto Read/Write 0: CCITT G3, 1: Auto
825-213 G3 Modem Mode For Ch 4 0~1 1: Auto Read/Write 0: CCITT G3, 1: Auto
825-214 G3 Modem Mode? For Ch 5 0~1 1: Auto Read/Write 0: CCITT G3, 1: Auto
825-215 G3 RX Modem Speed Receive Transmis-
sion Speed Capability (Capability except
V.34.) for Channel 0
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-216 G3 RX Modem Speed Receive Transmis-
sion Speed Capability (Capability besides
V.34.) for Channel 1
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27ter=0010, 2400 bps/V.27ter=0001
825-217 G3 RX Modem Speed Receive Transmis-
sion Speed Capability (Capability besides
V.34.) for Channel 2
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-218 G3 RX Modem Speed Receive Transmis-
sion Speed Capability (Capability besides
V.34.) for Channel 3
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-219 G3 RX Modem Speed Receive Transmis-
sion Speed Capability (Capability besides
V.34.) for Channel 4
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-220 G3 RX Modem Speed Receive Transmis-
sion Speed Capability (Capability besides
V.34.) for Channel 5
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-221 G3 RX Modem Speed Receive Communi-
cation Speed Capability (V.34 Capability)
for Channel 0
1~8 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
