January 2007
6-158
WorkCentre 7132
Controller & Fax NVM List
Reversion 4.0
General procedures information
825-222 G3 RX Modem Speed Receive Communi-
cation Speed Capability (V.34 Capability)
for Channel 1
1~8 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-223 G3 RX Modem Speed Receive Communi-
cation Speed Capability (V.34 Capability)
for Channel 2
1~8 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-224 G3 RX Modem Speed Receive Communi-
cation Speed Capability (V.34 Capability)
for Channel 3
1~8 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-225 G3 RX Modem Speed Receive Communi-
cation Speed Capability (V.34 Capability)
for Channel 4
1~8 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-226 G3 RX Modem Speed Receive Communi-
cation Speed Capability (V.34 Capability)
for Channel 5
1~8 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-227 Maximum G3 TX Modem Speed (Send)
(Capability except V.34) for Channel 0
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-228 Maximum G3 TX Modem Speed (Send)
(Capability except V.34) for Channel 1
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-229 Maximum G3 TX Modem Speed (Send)
(Capability except V.34) for Channel 2
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-230 Maximum G3 TX Modem Speed (Send)
(Capability except V.34) for Channel 3
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-231 Maximum G3 TX Modem Speed (Send)
(Capability except V.34) for Channel 4
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-232 Maximum G3 TX Modem Speed (Send)
(Capability except V.34) for Channel 5
1~8 14400bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
