Xerox WorkCentre 7132

January 2007
6-159
WorkCentre 7132
Controller & Fax NVM List
General procedures information
Reversion 4.0
825-233 Maximum G3 TX Modem Speed (Send)
(Capability except V.34.) for Channel 0 (To
be referred to in overseas communication)
1~8 4800bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-234 Maximum G3 TX Modem Speed (Send)
(Capability except V.34.) for Channel 1 (To
be referred to in overseas communication)
1~8 4800bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-235 Maximum G3 TX Modem Speed (Send)
(Capability except V.34.) for Channel 2 (To
be referred to in overseas communication)
1~8 4800bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-236 Maximum G3 TX Modem Speed (Send)
(Capability except V.34.) for Channel 3 (To
be referred to in overseas communication)
1~8 4800bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-237 Maximum G3 TX Modem Speed (Send)
(Capability except V.34.) for Channel 4 (To
be referred to in overseas communication)
1~8 4800bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-238 Maximum G3 TX Modem Speed (Send)
(Capability except V.34.) for Channel 5 (To
be referred to in overseas communication)
1~8 4800bps Read/Write 1.~ 8, 14400 bps/V.17=1000, 12000 bps/V.17=0111, 9600 bps/
V.17=0110, 7200 bps/V.17=0101, 9600 bps/V.29=0100, 7200
bps/V.29=0011, 4800 bps/V.27=0010, 2400 bps/V.27=0001
825-239 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 0
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-240 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 1
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-241 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 2
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-242 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 3
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-243 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 4
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
