825-244 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 5
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-245 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 0 (To be
referred to in overseas communication)
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-246 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 1 (To be
referred to in overseas communication)
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-247 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 2 (To be
referred to in overseas communication)
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-248 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 3 (To be
referred to in overseas communication)
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-249 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 4 (To be
referred to in overseas communication)
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-250 Maximum G3 TX Modem Speed (Send)
(V.34 capability) for Channel 5 (To be
referred to in overseas communication)
1~14 33600bps Read/Write 1~14, 33600 bps=1110, 31200 bps=1101, 28800 bps=1100,
26400 bps=1011, 24000 bps=1010, 21600 bps=1001, 19200
bps=1000, 16800 bps=0111, 14400 bps=0110, 12000 bps=0101,
9600 bps=0100, 7200 bps=0011, 4800 bps=0010, 2400
bps=0001
825-251 G3 RX Cable Equalizer for Channel 0 0~3 1: 4dB Read/Write 0: 0dB, 1: 4dB, 2: 8dB, 3: 12dB
825-252 G3 RX Cable Equalizer for Channel 1 0~3 1: 4dB Read/Write 0: 0dB, 1: 4dB, 2: 8dB, 3: 12dB
825-253 G3 RX Cable Equalizer for Channel 2 0~3 1: 4dB Read/Write 0: 0dB, 1: 4dB, 2: 8dB, 3: 12dB
825-254 G3 RX Cable Equalizer for Channel 3 0~3 1: 4dB Read/Write 0: 0dB, 1: 4dB, 2: 8dB, 3: 12dB
825-255 G3 RX Cable Equalizer for Channel 4 0~3 1: 4dB Read/Write 0: 0dB, 1: 4dB, 2: 8dB, 3: 12dB
825-256 G3 RX Cable Equalizer for Channel 5 0~3 1: 4dB Read/Write 0: 0dB, 1: 4dB, 2: 8dB, 3: 12dB
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
