Xerox WorkCentre 7132

January 2007
4-46
WorkCentre 7132
REP 4.2.7
Reversion 4.0
Repairs/Adjustments
Figure 6 Adding the new Developer Material
10. Prepare to reinstall the Developer Housing cover. (Figure 7)
Figure 7 Preparing to reinstall the Developer Housing Cover
11. Press the Cover tabs to lock the Developer Housing Cover. (Figure 8)
Install the inboard end
first
