Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
below.
In the following table:
–
The Enumerated ID is used with :DISP:SEM:VIEW
–
The Numeric ID is used with :DISP:SEM:VIEW:NSEL
View Name Enumerated ID Numeric ID Details
"Abs Pwr Freq"
on page 1021
APFReq
1 Displays the absolute power levels in dBm
and the corresponding frequencies in the
text window
"Rel Pwr Freq"
on page 1021
RPFReq
2 Displays the relative power levels in dBc
and the corresponding frequencies in the
text window
"Integrated
Power" on page
1021
IPOWer
3 Displays the absolute and relative power
levels integrated throughout the
bandwidths between the start and stop
frequencies in the text window
View Selection by Name
Remote Command
:DISPlay:SEMask:VIEW[:SELect] APFReq | RPFReq | IPOWer | CINFormation
:DISPlay:SEMask:VIEW[:SELect]?
Example
:DISP:SEM:VIEW IPOW
:DISP:SEM:VIEW?
Dependencies In SA Mode, when Radio Standard is set to WLAN, IPOWer is not available
CINFormation is available only in MSR, LTE-Advanced FDD/TDD and 5G NR Modes
Preset APFReq unless noted below
RPFReq WLAN
State Saved Saved in instrument state
Range Abs Pwr Freq| Rel Pwr Freq|Integrated Power|Carrier Info
Views Selection by Number
Remote Command
:DISPlay:SEMask:VIEW:NSELect <integer>
:DISPlay:SEMask:VIEW:NSELect?
Example
:DISP:SEM:VIEW:NSEL 2
:DISP:SEM:VIEW:NSEL?
Dependencies In SA Mode, when Radio Standard is set to WLAN, Option 3 is not available
Option 4 is available only in MSR, LTE-Advanced FDD/TDD and 5G NR Modes
1020 Short Range Comms & IoT Mode User's &Programmer's Reference
