3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
Sample Time (Display Only)
Display the total sample time of saved IQ data file.
3.3.10 Trace
The Trace menu lets you control the acquisition, display, storage, detection and
manipulation of trace data for the available traces.
3.3.10.1 Trace Control
The controls on the Trace Control tab allow you to set the type of the Trace.
Trace Display
Toggles the demod waveform traces display between On and Off.
Remote Command Toggle Demod Trace display On/Off
:DISPlay:LORA:TRACe:DEMod[:STATe] OFF | ON | 0 | 1
:DISPlay:LORA:TRACe:DEMod[:STATe]?
Toggle Demod Max Trace display On/Off
:DISPlay:LORA:TRACe:DMAXimum[:STATe] OFF | ON | 0 | 1
:DISPlay:LORA:TRACe:DMAXimum[:STATe]?
Toggle Demod Min Trace display On/Off
:DISPlay:LORA:TRACe:DMINimum[:STATe] OFF | ON | 0 | 1
:DISPlay:LORA:TRACe:DMINimum[:STATe]?
Toggle Demod Average Trace display On/Off
:DISPlay:LORA:TRACe:DAVerage[:STATe] OFF | ON | 0 | 1
:DISPlay:LORA:TRACe:DAVerage[:STATe]?
Example
:DISP:LORA:TRAC:DEM OFF
Turn off the Demod trace display
:DISP: LORA:TRAC:DEM?
:DISP: LORA:TRAC:DMAX OFF
Turn off the Demod Max trace display
:DISP: LORA:TRAC:DMAX?
:DISP: LORA:TRAC:DMIN OFF
Turn off the Demod Min trace display
:DISP: LORA:TRAC:DMIN?
Short Range Comms & IoT Mode User's &Programmer's Reference 429
