Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
State Saved Saved in instrument state
Range
ON|OFF
Backwards Compatibility
SCPI
[:SENSe]:MCPower:LIMit[:STATe]
[:SENSe]:ACPower:LIMit[:STATe]
Spur Avoidance
Because VXT models M9410A/11A/15A are direct-conversion (zero-IF) receivers,
feedthrough leakage from the local oscillator appears as a spurious signal (spur) at
the center frequency. The Spur Avoidance function is provided to eliminate this
spur, at the expense of some measurement speed.
When Spur Avoidance is enabled (the default), the instrument uses a software
algorithm to remove this spur from the displayed measurement data, but the
algorithm only operates under certain conditions. Specifically, it only operates in
multiple capture case.
You can disable this function to speed up your measurement by setting Spur
Avoidance to Disabled.
Note that when Spur Avoidance is not in effect, either because you have disabled it
or because you are not in multiple capture, the following warning message appears
in the status bar:
Settings Alert;Spur Avoidance Off
This is to alert you that measurement accuracy might be impacted by the fact that
Spur Avoidance is not in effect.
Remote Command
[:SENSe]:ACPower:SAVoid[:STATe] ON | OFF | 0 | 1
[:SENSe]:ACPower:SAVoid[:STATe]?
Example
:ACP:SAVoid ON
:ACP:SAVoid?
Dependencies Only appears in VXT models M9410A/11A/15A
Preset
OFF
State Saved Saved in instrument state
Range
ON|OFF
Meas Setup Summary Table
Lets you view and access many of the parameters in the Meas Setup menus on one
screen.
Short Range Comms & IoT Mode User's &Programmer's Reference 903
