Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
:DISP: LORA:TRAC:DAV OFF
Turn off the Demod Average trace display
:DISP: LORA:TRAC:DAV?
Dependencies The max demod trace, the min demod trace and the average demod trace are only visible when the
averaging is on
Preset
ON
State Saved Saved in instrument state
Range On|Off
Reference Selection
Selects the one of the following traces as a reference trace for comparison: the
demod trace, the max demod trace, the min demod trace or the average demod
trace.
Remote Command
:CALCulate:LORA:RTRace:SELect DEMod | DAVerage | DMAXimum | DMINimum
:CALCulate:LORA:RTRace:SELect?
Example
:CALC:LORA:RTR:SEL DEM
:CALC:LORA:RTR:SEL?
Notes DEMod: the demod trace
DAVerage: the average demod trace
DMAXimum: the max demod trace
DMINimum: the min demod trace
Dependencies The entries of the average trace, the max trace and the min trace in the dropdown gray out when the
averaging is off. An error message will appear if you are trying to access them on GUI
Preset
DEMod
State Saved Saved in instrument state
Store Reference
Refreshes the reference trace for comparison.
Remote Command
:CALCulate:LORA:RTRace:STORe
Example
:CALC:LORA:RTR:STOR
Dependencies The stored trace will be purged if the following parameters change:
The demod waveform time, the demod waveform offset, and the demod waveform points
Show Reference
Toggles the reference trace’s state between On and Off for display.
430 Short Range Comms & IoT Mode User's &Programmer's Reference
