Keysight x-series Instruction Manual

7 Save/Recall/Print
7.2 Recall
NOTE
Returns a string for waveform segment names in ARB memory. If you want a
string list of waveform segments in the ARB memory, use "Query ARB Memory
Full File List (Remote Query Only)" on page 2243.
Remote Command
:SOURce:RADio:ARB:CATalog?
Example
:SOUR:RAD:ARB:CATalog?
Notes The return data is in the following format:
<integer>
memory used
<integer>
memory free
<string>…
comma separated list of waveform segments within ARB memory
7.2.29 Query ARB Memory Full File List (Remote Query Only)
Queries the instrument for the string list of waveform segments in the ARB memory.
Returns a string list for waveform segment names in the ARB memory.
Remote
Command
:SOURce:RADio:ARB:FCATalog?
Example
:SOUR:RAD:ARB:FCATalog?
Notes The return data is in the following format:
<integer>
Memory used
<integer>
Memory free
<integer>
File count in ARB memory
<string>,<string>, …
<string>
Comma-separated string list of waveform segments within
ARB memory
Example:
:SOUR:RAD:ARB:FCAT?
EXT returns: 27499,2069653,3,”c2k.wfm”,”gsm.wfm”,”wcdma.wfm”
7.2.30 Power Sensor Cal Factor
Selects a file to which to export the Power Sensor Cal factor data.
Cal Factor files are XML files, and contain the cal factor data and header data that
gives information on the power sensor.
The default path for Cal Factor Files is:
My Documents\<mode name>\data\PSCF
Short Range Comms & IoT Mode User's &Programmer's Reference 2243
