3 Short-Range Comms & IoT Mode
3.12 Monitor Spectrum Measurement
NOTE
Pressing the Peak Search hardkey automatically moves you to the Peak Search
page of the Marker menu and performs a Peak Search.
If the selected marker was off, then it is turned on as a normal marker, and a
Peak Search is performed.
Remote
Command
:CALCulate:MONitor:MARKer[1]|2|...|12:MAXimum
Example
:CALC:MON:MARK2:MAX
:SYST:ERR?
can be used to query the errors to determine if a peak is found. If a search is unsuccessful, then the
message “Execution error; No peak found” (-200) will be returned
Notes Sending this command selects the subopcoded marker
Next Peak
Moves the selected marker to the peak that is next lower in amplitude than the
current marker value. If there is no valid peak lower than the current marker value,
an “Execution error; No peak found” message is generated and the marker is not
moved.
If the selected marker was off, then it is turned on as a normal marker and a peak
search is performed.
Remote
Command
:CALCulate:MONitor:MARKer[1]|2|...|12:MAXimum:NEXT
Example
:CALC:MON:MARK2:MAX:NEXT
selects marker 2 and moves it to the peak that is next lower in amplitude than the current marker value
Notes Sending this command selects the subopcoded marker
State Saved Not part of saved state
Marker Delta
Pressing this control has exactly the same effect as selecting the Delta selection in
"Marker Mode" on page 1699 on the Settings tab. The selected marker becomes a
Delta Marker. If the selected marker is already a Delta marker, the reference marker
is moved to the current position of the selected marker, thus resetting the Delta to
zero.
The control is duplicated here to allow you to conveniently perform a peak search
and change the marker’s control mode to Delta without having to access two
separate menus.
1702 Short Range Comms & IoT Mode User's &Programmer's Reference
