3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
Example
:DISP:SEM:WIND:TRAC:X:PDIV 500
:DISP:SEM:WIND:TRAC:X:PDIV?
Couplings If Auto Scaling is ON, this value is automatically determined by the measurement result. When you set
this value manually, Auto Scaling automatically changes to OFF
Preset Automatically Calculated
State Saved Yes Saved in instrument state
Min 1 Hz
Max 100 GHz
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:PDIVision
Ref Position
Sets the reference position for the X axis to Left, Center or Right.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RPOSition LEFT | CENTer | RIGHt
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RPOSition?
Example
:DISP:SEM:WIND:TRAC:X:RPOS LEFT
:DISP:SEM:WIND:TRAC:X:RPOS?
Preset
CENTer
State Saved Saved in instrument state
Range Left|Center|Right
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RPOSition
Auto Scaling
Toggles the scale coupling function On or Off.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:COUPle?
Example
:DISP:SEM:WIND:TRAC:X:COUP ON
:DISP:SEM:WIND:TRAC:X:COUP?
Couplings When Auto Scaling is ON and the Restart front-panel key is pressed, this function automatically
determines the scale per division and reference values based on the measurement results
When you set a value to either "Scale/Div" on page 1192 or "Ref Value" on page 1192 manually, Auto
Scaling automatically changes to OFF
Short Range Comms & IoT Mode User's &Programmer's Reference 1193

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
