6 Input/Output
6.2 Input
Example
:AFIN:COUP AC
Dependencies Only appears in Measuring Receiver Mode and Radio Test Mode
In Measuring Receiver Mode, only appear in Audio Measurements, and only if Option 107 is present
In Radio Test Mode, only appears in modular products, and only if an M9260A Audio Analyzer module
is installed
Preset
AC
6.2.26 Audio Input Ground
Lets you float or ground the low side of the currently selected audio input channel.
When you choose FLOat, the low side of the input is disconnected from ground.
Remote Command
[:SENSe]:AFINput[1]|2:LOW FLOat | GROund
[:SENSe]:AFINput[1]|2:LOW?
Example
:AFIN2:LOW FLO
Dependencies Only appears in Radio Test Mode
Only appears in modular products, and only if an M9260A Audio Analyzer module is installed
Preset Unaffected by Mode Preset, but set to GROund by Input/Output Preset
6.2.27 Audio In Impedance
Lets you set the Impedance of the currently selected audio input channel.
The value you enter is rounded up to the nearest allowed value.
Remote Command
[:SENSe]:AFINput[1]|2:IMPedance 50 | 600 | 1000000
[:SENSe]:AFINput[1]|2:IMPedance?
Example
:AFIN:IMP 50
Dependencies Only appears in Radio Test Mode
Only appears in modular products, and only if an M9260A Audio Analyzer module is installed
Preset Unaffected by Mode Preset, but set to 600 by Input/Output Preset
6.2.28 Input/Output Preset
Resets the group of settings and data associated with the Input/Output front-panel
key to their default values. These settings are not affected by Mode Preset because
they are generally associated with connections to the instrument, which you
generally would not want to reset every time you press Mode Preset.
2093 Short Range Comms & IoT Mode User's &Programmer's Reference
