Keysight x-series Instruction Manual

6 Input/Output
6.5 Corrections
When this key is pressed a prompt is placed on the screen that says “Please press
Enter or OK key to delete all corrections. Press ESC or Cancel to close this dialog.”
The deletion is only performed if you press OK or Enter.
Remote
Command
[:SENSe]:CORRection:CSET:ALL:DELete
Example
:CORR:CSET:ALL:DEL
6.5.10 Correction Group On/Off
Turns the Correction Group on and off. The Correction Group allow you to preload
Correction files and associate them with specific frequency ranges, so that they can
be switched in and out during a sweep at the appropriate frequencies. Use the
control “Edit Correction Group” below to set up your Correction Group.
The state of each Correction will be set dynamically depending on the active
measurement frequency. Only the correction selected for the range that matches
the active measurement frequency will be turned on, and vice versa.
Note that the Corrections in the Correction Group, although they are loaded into
memory, are independent of the main Correction registers at the top of the
Corrections menu, and will not display under the Select Correction, Correction
On/Off or Edit Correction functions.
Remote Command
[:SENSe]:CORRection:CSET:GROup[:STATe] ON | OFF | 1 | 0
[:SENSe]:CORRection:CSET:GROup[:STATe]?
Example
:SENS:CORR:CSET:GRO ON
Dependencies Correction group is supported in EMI Receiver Mode, and in Spectrum Analyzer Mode if option EMC
or EMI Receiver Mode is present. If you switch to other measurements or modes, correction group is
turned off and the Correction Group functions are not visible
Couplings When on, Correction 1 through 8 is set to OFF and the correction on/off state keys are grayed out. If
the grayed-out key is pressed, it generates an advisory message. If sending the SCPI to turn it on, this
same message is generated as part of Settings conflict
Preset Not affected by Preset. Set to OFF by Restore Input/Output Defaults
State Saved Saved in instrument state
6.5.11 Break
If break is turned on, the scan or sweep will be paused when it reaches the boundary
of correction group ranges. At the same time, a window at the size of ~ 6.5cm x 3.5
cm is prompt at the upper right-hand corner of the graticule.
When running Frequency Scan measurement of Emi Receiver application, the
message prompt is like below. You are given the option to resume the scan or stop
the scan.
Short Range Comms & IoT Mode User's &Programmer's Reference 2134

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
