3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Mode Values
SA 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0,0
WCDMA 1, 1, 1, 1, 1, 1 | 1, 1, 1, 1, 1, 1
LTEAFDD, LTEATDD, 5G NR, MSR 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0,0
Radio Test 0, 0, 0, 0, 0, 0
State Saved Saved in instrument state
Range Integ BW | RRC Weighted
Filter Alpha
Sets the alpha value for the RRC Filter for each offset.
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:FILTer:ALPHa <real>,…
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:FILTer:ALPHa?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:LIST:FILT:ALPH 0.5,0.5,0.5,0.5,0.5,0.5
:ACP:OFFS:LIST:FILT:ALPH?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is the same as the Offset
F value
SA 0.22,0.22,0.22,0.22,0.22,0.22|0.22,0.22,0.22,0.22,0.22,0.22
WCDMA 0.22,0.22,0.22,0.22,0.22,0.22|0.22,0.22,0.22,0.22,0.22,0.22
LTEAFDD, LTEATDD, 5G NR,
MSR
0.22,0.22,0.22,0.22,0.22,0.22|0.22,0.22,0.22,0.22,0.22,0.22
State Saved Saved in instrument state
Min/Max 0.01/1.00
Advanced (Offset)
Opens a further menu page, which lets you set advanced properties of the Inner
Offset, such as Res BW, Video BW, and Filter parameters.
Offset Freq
This column is the same as "Offset Freq" on page 915 in the main Offset menu.
920 Short Range Comms & IoT Mode User's &Programmer's Reference
