Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
Example
:DISP:HUWB:WIND3:X:WIDT 10e6
set the X width of the third window to 10 MHz
:DISP:HUWB:WIND3:X:WIDT?
query the X width of the third window
Couplings If "Auto Scaling" on page 536 is ON, the X Width is determined by the trace data
Preset Depends on trace data
State Saved Yes
Min -9.9E+37
Max 9.9E+37
Ref Value
Controls the X value of the selected trace at the chosen X Reference Position.
Remote Command
:DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:RLEVel <real>
:DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:RLEVel?
Example
:DISP:HUWB:WIND4:TRAC:X:RLEV 10
:DISP:HUWB:WIND4:TRAC:X:RLEV?
Preset Depends on trace data
State Saved Saved in instrument state
Min -9.9E+37
Max 9.9E+37
Ref Position
Determines the position from which the X scaling is calculated for the selected
trace. It can be set to the left side, center, or right side of the grid.
Remote
Command
:DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:RPOSition LEFT | CENTer | RIGHt
:DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:RPOSition?
Example
:DISP:HUWB:WIND3:X:RPOS CENT
set the X ref position of the third window to CENT
:DISP:HUWB:WIND3:X:RPOS?
query the X ref position of the third window
Preset Depends on trace data
State Saved Yes
Range
LEFT|CENTer|RIGHt
Short Range Comms & IoT Mode User's &Programmer's Reference 535
